Tủ trung tâm báo cháy thông thường 4 zone

Xuất xứ: Trung Quốc Bảo hành: 24

Liên hệ

Mã SP: DHI-HY-C102-4

Số Lượng

THÔNG TIN SẢN PHẨM

DHI-HY-C102-4 Conventional Fire Alarm Control Panel is designed and manufactured in compliance with EN54 Parts 2 & 4 requirements. As the core of conventional fire alarm system, it cooperates with smoke detectors, heat detectors, sounder strobes, and manual call points to construct a fire alarm control system. With Ethernet, RS-485, and other IoT interfaces, it can integrate with other panels and connect to platforms.

THÔNG SỐ KỸ THUẬT

Number of Zones	4
Zone Capacity	32 detectors per zone
Main Power	AC90-240V/50Hz, 60Hz
Backup Power	2 lead-acid batteries (12V/5Ah each)
Output Current	2A
Sounder Output	Fault: 50dB Alarm: 60dB
Fire Bell Output	DC 28V/500mA
Dimensions	310.0 mm×73.0 mm×227.0 mm (12.20" × 2.87" × 8.94")
Weight	3.5 kg 5 kg (with 2 batteries)
Operating Temperature	–10°C to +50°C (+14°F to +122°F)
Operating Humidity	≤ 95% RH (no condensation)
Protection Grade	IP30
Installation	Wall mount
Compliance Standard	EN54-2,EN54-4
